[email protected]

24/7 Customer Support

+86-13761906384

24/7 Customer Support

What is 00Cr17 Material?

00Cr17 material is added titanium and niobium based on 430 stainless steel and then reduces the carbon content, thus improving the processing performance, and welding main corrosion resistance.

00Cr17 Material strips

00Cr17 Material Corresponding Grades

1, GB-T standard: digital sign: S11863, the new sign: 022Cr18Ti, the old sign: 00Cr17,

2, American Standard: ASTMA standard: S43035, SAE standard: 430Ti, UNS standard: 439.

3, Japanese standard JIS standard: sus430 LX.

4, German standard DIN standard: 1. 4510,

5, European standard EN standard: X3CrTi17.

00Cr17 Material Chemical Composition

(1) C: ≤ 0.030.

(2) Si: ≤ 0.75.

(3) Mn: ≤ 1.00

(4) P: ≤ 0.040.

(5) S: ≤ 0.030.

(6) Cr: 16.00 ~ 19.00.

(7) Ni: allow plus ≥ 0.60.

(8) Other elements: Ti or Nb: 0.10 ~ 1.00.

00Cr17 Physical Properties

① Density Density(20℃)/kg/dm3:7.7,

②Melting point / ℃:1365

③Specific heat capacity (0~100℃)/kg/(kg.k):0.46,

④ Thermal conductivity/w/(m.k)100℃-:35.1,

⑤ Thermal conductivity/w/(m.k)500℃-: -,

⑥ Coefficient of linear expansion/(10-6/k) 0~100℃:10.4,

⑦ Linear expansion coefficient /(10-6/k)0~579℃: -,

⑧ Resistivity (20℃)/(.mm2/m):0.6,

⑨ Longitudinal modulus of elasticity(20℃)/GPa:200.

⑩Magnetic:Yes.

00Cr17 Mechanical Properties

(1) delivery status: bar solid solution treatment, plate solid solution pickling.

(2) tensile strength (RM/MPa): 365.

(3) elongation strength (Rp0.2/MPa): 175.

(4) Elongation A/%: 22.

(5) section shrinkage (Z / %): –

00Cr17 Heat Treatment

① hardness HBW ≤: annealed 183, hardness HRB ≤: 88,

② heating temperature: 780 ~ 950,

③ heating mode: air cooling or slow cooling.

00Cr17 application areas: used in the manufacture of warm water tanks, hot water supply, sanitary appliances, household use of durable machines, etc..

Share:

Facebook
Twitter
Pinterest
LinkedIn

Contact Us For Metal Prices

Table of Contents

On Key

Related Posts

Carbon steel Knives, Knife Making Steel

Knife Making Steel

In the field of Knife Making Steel, the choice of steel determines the performance, durability and user experience of the knife. Different types of knife

Titanium vs Aluminum, aluminum vs titanium, aluminium vs titanium, aluminum versus titanium

Titanium vs Aluminum

When choosing between titanium vs aluminum, it is important to understand the differences in weight, strength, corrosion resistance, and applications. Both metals are widely used

Welcome
